PTFE Coated Fabric Roll for Non-Stick and Heat Resistant Applications
Dense PTFE-coated E-glass fiberglass fabric for non-stick release and high-temperature process applications.
Product overview
Dense PTFE-coated E-glass fiberglass fabric for non-stick release and high-temperature process applications.
Product highlights
- Dense PTFE-coated fiberglass release surface
- Low-friction, non-stick surface characteristics
- Fiberglass reinforcement for dimensional stability
- Roll, sheet and converted-part formats
- Final thickness, coating grade and process suitability confirmed by specification
Procurement data
Technical specifications
Final specifications are confirmed against operating conditions and order requirements.
| Specification | Details |
|---|---|
| Product Name | PTFE Coated Fabric Roll |
| Material | PTFE-coated E-glass fiberglass fabric with a dense, non-mesh surface; coating grade and construction must be confirmed |
| Surface | Dense PTFE-coated fiberglass release surface |
| Reinforcement | Woven E-glass fiberglass fabric |
| Temperature Range | Typical continuous operating range: -70°C to +260°C for the selected PTFE-coated fiberglass fabric grade; do not use the PTFE resin melting point as a product operating limit. |
| Airflow / permeability | Construction-dependent |
| Food Contact / Documents | Food-contact suitability is available only for a selected, documented final PTFE-coated fabric grade and intended use. |
| Non-stick Performance | High-performance PTFE non-stick release surface |
| Sample Availability | Sample availability is confirmed after the material and specification review. |
| Lead Time | Lead time is confirmed after the selected material, specification, quantity, processing and packaging are approved. |
| Applications | Bakery tray liners, oven release sheets, food processing liners, heat sealing machines, packaging equipment, conveyor release surfaces, industrial non-stick lining, insulation wrapping |
Selection support
Guides for this product
- Custom PTFE Fabric: Sizes, Grades & MOQ
Plan slit rolls from 10 m², cut sheets from 50 pieces and new material constructions from 500 m². Compare fabrication and OEM packaging minimums.
- PTFE Fusing Machine Belts: Surface Finish, Splice and Tracking Selection
Select a garment fusing belt by release surface, splice profile and machine fit. Compare fabric marking, adhesive build-up and tracking with a controlled sample trial.
End-use fit
Applications
Typical purchasing use cases for this product family.
- Bakery tray liners
- oven release sheets
- food processing liners
- heat sealing machines
- packaging equipment
- conveyor release surfaces
- industrial non-stick lining
- insulation wrapping
Purchasing questions
Frequently asked questions
Product-specific answers for sampling, customization and production planning.
Can you supply PTFE coated fabric rolls in custom widths and lengths?
Yes. We can provide standard roll widths as well as slit rolls, custom roll lengths and cut sheets based on your application requirements.
What should I specify for a PTFE Coated Fabric Roll quotation?
Please share thickness, width, roll length, color, application, temperature requirement, quantity and whether you need sheet cutting or other converting services.
Can I approve a PTFE Coated Fabric Roll sample before bulk production?
Sample availability depends on the requested grade and approved material availability. Sample confirmation is recommended for new projects or custom converting orders.
Is this material suitable for food processing use?
Food-contact suitability depends on the specific material grade and your application conditions. Please confirm the intended use with us before ordering.
How are packaging, samples and lead time confirmed for PTFE Coated Fabric Roll?
Labels start from 100 pcs; retail sleeves or header cards start from 1,000 pcs; printed colour boxes start from 3,000 pcs per artwork. Sample availability is confirmed after the material and specification review. Lead time is confirmed after the selected material, specification, quantity, processing and packaging are approved. MOQ, packing configuration and delivery schedule are confirmed after the final material, dimensions and quantity are approved.
Discuss your requirement
Request a quote for PTFE Coated Fabric Roll
Share dimensions, quantity, operating conditions, packaging and documentation needs. We will follow up with the next specification steps.
