PTFE Coated Fiberglass Fabric for Non-Stick and Heat Resistant Use
Dense PTFE-coated E-glass fiberglass fabric for non-stick release and high-temperature process applications.
Product overview
Dense PTFE-coated E-glass fiberglass fabric for non-stick release and high-temperature process applications.
Product highlights
- Dense PTFE-coated fiberglass release surface
- Low-friction, non-stick surface characteristics
- Fiberglass reinforcement for dimensional stability
- Roll, sheet and converted-part formats
- Final thickness, coating grade and process suitability confirmed by specification
Procurement data
Technical specifications
Final specifications are confirmed against operating conditions and order requirements.
| Specification | Details |
|---|---|
| Product Name | PTFE Coated Fiberglass Fabric |
| Material | PTFE-coated E-glass fiberglass fabric with a dense, non-mesh surface; coating grade and construction must be confirmed |
| Surface | Dense PTFE-coated fiberglass release surface |
| Reinforcement | Woven E-glass fiberglass fabric |
| Temperature Range | Typical continuous operating range: -70°C to +260°C for the selected PTFE-coated fiberglass fabric grade; do not use the PTFE resin melting point as a product operating limit. |
| Airflow / permeability | Construction-dependent |
| Food Contact / Documents | Food-contact suitability is available only for a selected, documented final PTFE-coated fabric grade and intended use. |
| Non-stick Performance | High-performance PTFE non-stick release surface |
| Sample Availability | Sample availability is confirmed after the material and specification review. |
| Lead Time | Lead time is confirmed after the selected material, specification, quantity, processing and packaging are approved. |
| Applications | Bakery tray liners, oven liners, heat sealing and packaging equipment, food processing liners, conveyor release surfaces, industrial insulation and non-stick lining |
Selection support
Guides for this product
- Custom PTFE Fabric: Sizes, Grades & MOQ
Plan slit rolls from 10 m², cut sheets from 50 pieces and new material constructions from 500 m². Compare fabrication and OEM packaging minimums.
- PTFE Fusing Machine Belts: Surface Finish, Splice and Tracking Selection
Select a garment fusing belt by release surface, splice profile and machine fit. Compare fabric marking, adhesive build-up and tracking with a controlled sample trial.
- PTFE Fabric and Tape for Heat Sealers: Thickness, Adhesive and Failure Diagnosis
Choose PTFE fabric and tape for heat sealers by backing thickness, adhesive layout and contact conditions. Diagnose sticking, wrinkles and local wear before replacing.
End-use fit
Applications
Typical purchasing use cases for this product family.
- Bakery tray liners
- oven liners
- heat sealing and packaging equipment
- food processing liners
- conveyor release surfaces
- industrial insulation and non-stick lining
Purchasing questions
Frequently asked questions
Product-specific answers for sampling, customization and production planning.
Can you supply PTFE coated fiberglass fabric in different thicknesses?
Yes. Multiple standard thicknesses are available, and custom thickness selection can be discussed based on your application and order quantity.
Can this material be supplied in rolls and cut sheets?
Yes. We can supply full rolls, slit rolls and cut-to-size sheets according to width, length and packaging requirements.
What should I specify for a PTFE Coated Fiberglass Fabric quotation?
Please provide required thickness, width, roll length or sheet size, color, application, temperature requirement, quantity and any converting or packaging needs.
Can I approve a PTFE Coated Fiberglass Fabric sample before bulk production?
Sample availability depends on the requested specification and approved material availability. Sample confirmation is recommended for new projects and custom converting orders.
How are packaging, samples and lead time confirmed for PTFE Coated Fiberglass Fabric?
Labels start from 100 pcs; retail sleeves or header cards start from 1,000 pcs; printed colour boxes start from 3,000 pcs per artwork. Sample availability is confirmed after the material and specification review. Lead time is confirmed after the selected material, specification, quantity, processing and packaging are approved. MOQ, packing configuration and delivery schedule are confirmed after the final material, dimensions and quantity are approved.
Discuss your requirement
Request a quote for PTFE Coated Fiberglass Fabric
Share dimensions, quantity, operating conditions, packaging and documentation needs. We will follow up with the next specification steps.
